Starter for Forklifts

Starters for Forklift - The starter motor of today is typically either a series-parallel wound direct current electric motor that has a starter solenoid, which is similar to a relay mounted on it, or it can be a permanent-magnet composition. As soon as current from the starting battery is applied to the solenoid, basically via a key-operated switch, the solenoid engages a lever which pushes out the drive pinion which is positioned on the driveshaft and meshes the pinion with the starter ring gear which is found on the flywheel of the engine.

The solenoid closes the high-current contacts for the starter motor, which begins to turn. When the engine starts, the key operated switch is opened and a spring in the solenoid assembly pulls the pinion gear away from the ring gear. This particular action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in just one direction. Drive is transmitted in this way through the pinion to the flywheel ring gear. The pinion continuous to be engaged, for example because the driver did not release the key when the engine starts or if there is a short and the solenoid remains engaged. This causes the pinion to spin separately of its driveshaft.

The actions mentioned above will prevent the engine from driving the starter. This vital step stops the starter from spinning very fast that it would fly apart. Unless modifications were done, the sprag clutch arrangement will preclude the use of the starter as a generator if it was made use of in the hybrid scheme discussed earlier. Typically an average starter motor is meant for intermittent use that will prevent it being used as a generator.

Thus, the electrical components are designed to be able to work for about under 30 seconds to avoid overheating. The overheating results from very slow dissipation of heat due to ohmic losses. The electrical components are designed to save cost and weight. This is actually the reason the majority of owner's manuals for vehicles recommend the operator to stop for a minimum of 10 seconds right after every ten or fifteen seconds of cranking the engine, when trying to start an engine that does not turn over instantly.

The overrunning-clutch pinion was introduced onto the marked during the early part of the 1960's. Before the 1960's, a Bendix drive was utilized. This drive system works on a helically cut driveshaft that has a starter drive pinion placed on it. As soon as the starter motor begins spinning, the inertia of the drive pinion assembly allows it to ride forward on the helix, therefore engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear allows the pinion to exceed the rotating speed of the starter. At this point, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.

The development of Bendix drive was made during the 1930's with the overrunning-clutch design referred to as the Bendix Folo-Thru drive, made and introduced in the 1960s. The Folo-Thru drive has a latching mechanism together with a set of flyweights within the body of the drive unit. This was an improvement for the reason that the standard Bendix drive utilized to be able to disengage from the ring as soon as the engine fired, although it did not stay running.

The drive unit if force forward by inertia on the helical shaft when the starter motor is engaged and begins turning. Afterward the starter motor becomes latched into the engaged position. As soon as the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for instance it is backdriven by the running engine, and after that the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement could be avoided prior to a successful engine start.
